Sizes (Wheel Diameters)
9.84 to 39.37(250 mm to 1,000 mm)
Performance
Air Flow to 235,294 CFM (400,000m3/hour)
Total Pressure to 10 inches w.g. (2500 Pa)
Characteristic：
Single inlet single width (SISW) centrifugal fans.
Backward inclined blades impeller.
Belt drive transmission.
Material:
- Carbon Steel
- Stainless steel Alloy SS 304/316
- Plastic materials
- FRP
Typical Applications
- Ventilation systems
- Conditioning
- Drying processes
- Cooling processes
- Mechanical draught
- Fumes/gas elimination
- Humidity regulation
