LBS-P,Centrifugal Plug Fans

9.84 to 39.37(250 mm to 1,000 mm)

Air Flow to 235,294 CFM (400,000m3/hour)

Total Pressure to 10 inches w.g. (2500 Pa)

Single inlet single width (SISW) centrifugal fans.
Backward inclined wheel .
Direct-coupled motor with impeller splined on the shaft

Features

Wheel:

Wheel dynamically balancing accuracy class with reference of ISO1940 &G4.5 class standard. The balancing accuracy can reach to G2.0

Deep spun cone, aerodynamically designed for smooth air entry into the wheel.

centrifugal fans Inlet Cone

Special Wheel

Custom Painting

Inlet Cone

Inlet Vane Control

Special Steel

Inlet Guard

Belt Guard

Inlet Flange
